| Item |
Specification |
| Type |
EH-AY22 |
EH-AY4V |
EH-AY4H |
EH-AY2H |
EH-AY4I |
EH-AYH8M |
| Voltage output range |
0 to 10V DC
(Ch. 0 to 1 ) |
0 to 10V DC |
-10 to 10V DC |
— |
0 to 10V DC |
| Current output range |
4 to 20mA
(Ch. 2 to 3) |
— |
4 to 20mA |
0 to 22mA
4 to 22mA |
| Resolution |
12 bits |
| Conversion time |
5 ms or less |
10 ms or less |
| Overall accuracy |
±1 % or less (of full-scale value) |
±0.8 %
of full scale
(0 to 5 SC) |
| External load resistor |
Voltage output |
10 kΩor more |
| Current output |
0 to 500Ω |
— |
0 to 350Ω |
10 to 400Ω |
| Insulation |
Channel - Internal circuit |
Photocoupler insulation |
| Between channels |
No insulation |
| Number of channels |
Voltage output |
2 channels /
module
(Ch. 0 to 1) |
4 channels /
module |
2 channels /
module |
— |
8 channels/
module
or
4 channels/
module
(ch.0 to 3 or
ch. 4 to 7) |
| Current output |
2 channels /
module
(Ch. 2 to 3) |
— |
4 channels /
module |
8 channels/
module
or
4 channels/
module
(ch.0 to 3 or
ch. 4 to 7) |
| Weight |
Approximately 0.18 kg (0.4 lb.) |
0.15 kg |
0.22 kg |
| External connection |
Removable screw terminal block (M3) |
Internal current
consumption (5V DC) |
Approximately 100mA |
130mA |
70mA |
| External power supply |
24 V DC (+20%, -15%)
Approximately 0.15 A
(Approximately 0.5 A at power On) |
24 V DC(+20%, -15%)
Approximately
0.25 A
(Approximately
0.8 A
at power On) |
| External wiring |
2-core shield wire (20 m (65.62 ft.) or less) |
