Serial Communication Module (EH-SIO)
| Item |
Specification |
| EH-SIO |
| Interface |
RS-232C×1
RS-232C/422 /485 |
| Transmission method |
Half-duplex |
| Transmission speed(bps) |
300/ 600/ 1200/
2400/ 48200/ 9600/ 19200/ 38400/ 57600 |
| Maximum transmission data |
Maximum 1024 byte |
| Transmission protocol |
Non-protocol
Modbus ASCII
Modbus RTU
HI-Protocol(*) |
| Others |
Simple data link
by Hi-protocol |
(*) For Touch panel / HMI (LADDER EDITOR cannot be used)
EH-SIO is supported by EH-CPU516 / 548
